Wulfsberg C-5000 User Manual

C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Page 4-26 Publication No. 150-041118
Section 4 – Electrical Installation Rev A
Sep 2001
NOTE: FC-50 Connector J3 connects to AT-50/AT-51 antennas. These pins provide proprietary
channeling information to the antenna.
PIN SIGNAL NAME PIN SIGNAL NAME
A Proprietary F
Proprietary
B Proprietary G Proprietary
C Proprietary H
Proprietary
D Proprietary J
Proprietary
E Proprietary K
Proprietary
Figure 4-8. FC-50 / FC-550 / FC-5000 Connector J3

Wulfsberg C-5000 Specifications

General

Brand	Wulfsberg
Model	C-5000
Category	Controller
Language	English
