Page | 86
5. Remove the Locking Clip in the Push to connect elbow fitting that is connected to the Flowmeter-Solenoid Module
and located behind the Right Regulator at the connection with the Tubing coming out of the Fridge. See Figure L4.
6. Disconnect the elbow fitting at the connection with the Tubing coming out of the Fridge. See Figure L5.
7. Remove all the screws holding the Rear Enclosure. There should be four (4) inside the Rear Enclosure and two (2)
outside. See Figure L6 and Figure L7.
Remove
Locking Clips
Figure L4: Controller Board Enclosure placed back in its original location.
Figure L5: Controller Board Enclosure placed
back in its original location.
Remove Two
screws
Figure L6: Outside Screws on the Rear Enclosure.
