8. Hold the Rear Enclosure with one hand and pull on the collet of the Push to connect straight fitting threaded into
the back of the Left Regulator. Use a 3/8” Open Ended Wrench if fingers hard to reach with fingers Once the push to
connect fitting on the Left Regulator is disconnected, the Rear Enclosure will pull right off. See Figure L8 and Figure
L9.
9. Place the Rear Enclosure next to the Fridge careful not to place any wires under strain or on any sharp edges that
may damage the wires. See Figure L10.
Figure L10: Rear Enclosure placed next to Fridge.
Figure L7: Inside Screws on the Rear Enclosure.
Remove
Four screws
Pull on Collet
to disconnect
Use Wrench
to pull collet
Figure L8: Push to connect joint shown.
Figure L9: Wrench used to pull on Collet.
