Insulation Blowing Machine M99
X-Floc Dämmtechnik-Maschinen GmbH Page 23 of 51
Rosine-Starz-Straße 12 · 71272 Renningen · Germany
Phone +49-7159-80470-30 · Fax -40 | info@x-floc.com · www.x-floc.com
5.3 Functionality
1
2
3
4
5
Figure 16: Functionality M99
The material (1) put through the insulation blowing machine will be broken up in the rotating conditioning
unit [9] (2) and transported to the airlock. The airlock feed gate (3) controls the insulation material volume in
the rotary airlock [8] (4). On the bottom of the airlock, the transported insulation material is accelerated from
the airlock chamber and blown through the conveyor line and carried out by the air flow via the outlet [7] (5).
