Onboard Control and Status Display Panel
975-0402-01-01 1–13
This guide for use by qualified installers only
Reverse Polarity Fuse
fault
Internal fault
Flashing LED Solid LED
Figure 1-5
Input Voltage Operating and De-rating Curve
Table 1-1
Fault and Warning Indicators
Fault or Warning
Condition
Temp Fan AC Battery Fuse Charger Remote Fault
F
u
s
e
C
h
g
r
R
e
m
Input
Voltage
80 85 90 104 108 255 265 270 volts
Fault LED blinks if current is derated
in this region.
Imax
0.8 Imax
TC2 Series BattChg Install Guide.book Page 13 Monday, June 30, 2008 3:18 PM
