Introduction
1–12 975-0402-01-01
This guide for use by qualified installers only
Low Battery Temp
fault (< -25°C)
See Figure 1-6.
AC input out of range
Warning (<104V and
>90V) or
(<264V and >255V)
See Figure 1-5.
AC input out of range
fault
(<90V or >265V)
See Figure 1-5.
AC frequency out of
range fault
(<45 Hz or >65 Hz)
High Battery voltage
fault (>16.6V)
High Charger Temp
warning (>50°C)
High Charger Temp
fault (>70°C)
Locked Fan fault
Loss of Remote
Connection warning
Flashing LED Solid LED
Table 1-1 Fault and Warning Indicators
Fault or Warning
Condition
Temp Fan AC Battery Fuse Charger Remote Fault
F
u
s
e
C
h
g
r
R
e
m
