Introduction
1–16 975-0402-01-01
This guide for use by qualified installers only
• Limit the maximum charger output current (20, 40, 60,
80, and 100% of charger rating) to lower the current
drawn from the generator or AC source
• Set the charger to
ON or on STANDBY
• Set or cancel an equalization cycle
• Display faults and warnings
• Display basic battery level and settings
Item Description
1
ON/STANDBY Button
• Press to enable or disable the charger while AC power is
connected.
• When in Setup Mode: Press to select the Charger Mode: two or
three-stage.
• To set or cancel an Equalization program: Press and hold both the
Status and
ON/STANDBY buttons.
2 Charging Output (%) LEDs
• The LEDs illuminate a progress bar displaying the present total
output charge current as a percentage of the maximum charge
current. The numbers below the LEDs represent the percentage
values. See 2a on Figure 1-7 on page 1–15.
NOTE: The charger maximum current can be set using the Remote
Panel.
• An LED may flash intermittently in combination with a solid Fault
LED to indicate a fault or with a flashing Fault LED to indicate a
warning condition. The icons on the right side of the LEDs
represent different types of faults and warnings. See 6a on Figure
1-7 on page 1–15.
TC2 Series BattChg Install Guide.book Page 16 Monday, June 30, 2008 3:18 PM
