Remote Panel (Sold Separately)
975-0402-01-01 1–17
This guide for use by qualified installers only
3 Charger Status LEDs
Displays the present status of the charger.
• Ready - a solid light indicates that all batteries are fully charged
and in rest stage.
• Ready and Charging - solid lights indicate that batteries are fully
charged and in float stage.
• Charging - a solid light indicates that the charger is performing a
normal charge cycle.
• Equalize - a solid light indicates that the charger is performing an
equalization cycle.
- a flashing light indicates that the equalization cycle
will begin after the absorption stage is done.
4 Battery Status LEDs
Displays the present status of each battery (or each battery bank).
Each row represents the battery (or battery bank) number
designation—1, 2, or 3. Each column represents Low, Medium, or
Full battery capacity.
NOTE: This feature is available only on the Remote Panel.
5 Status Button
• Press and hold to enter or exit Setup Mode.
• When in Setup Mode: Press to select the Battery Temperature:
C
old, Warm, or Hot.
• When setting or cancelling an Equalization program: Press and
hold both the Status and
ON/STANDBY buttons.
6 Fault/Warning LED
The LED displays a solid light to indicate a fault condition or flashes
intermittently in combination with a flashing Charging Output (%)
LED to display a warning condition (6a). See Table 1-1, “Fault and
Warning Indicators” on page 1–11 for details.
7 Set Max Output Button
• Press to select the desired maximum charging output current.
NOTE: This feature is available only on the Remote Panel.
• When in Setup Mode: Press to select the Battery Type: AGM,
Flooded, GEL, Lead-Calcium/OEM
8 Max. Output (%) LED
The LED illuminates a solid light corresponding to the Maximum
Charger Output % setting.
Item Description
TC2 Series BattChg Install Guide.book Page 17 Monday, June 30, 2008 3:18 PM
