Installation
2–6 975-0402-01-01
This guide for use by qualified installers only
rating means that it meets European and U.S. standards in
preventing dripping water from entering the enclosure, and
causing shock hazard and damage to equipment.
The other possible mounting orientations will not prevent the
entry of dripping water, and are not suitable for marine, or a
moist environment without the installation of additional drip
protection. They are only acceptable for use in locations that
are always dry [shown in Figure 2-2 c) and d)].
The environment, therefore, will determine the mounting
orientations that are suitable for each installation. Is the
installation environment one that will always be dry or will
moisture or condensation sometimes enter the area?
For marine installations, the mounting orientations a) and b)
in Figure 2-2 meet the North American and European marine
requirements. Marine products are required to meet drip-
proof tests to ensure safety in the presence of condensation.
If you are certain your installation is not subject to moisture,
mounting orientations c) and d) in Figure 2-2 may be used.
Important:
In marine environments, there is a likelihood that
condensation will be present, and may drip on to the charger. Use
the appropriate mounting orientations as shown in Figure 2-2.
TC2 Series BattChg Install Guide.book Page 6 Monday, June 30, 2008 3:18 PM
