Xantrex XDC User Manual

SCPI Command Reference
SCPI Command Summary
Release 3.0 201
Table B.3Commands for Output Control
Function
SCPI Command
Description Query
Set (Immediate) Current
Setpoint
[[:]SOURce][<channel>]:CURRent[:LEVel][:IMMediate][:A
MPLitude] {<current>|MAXimum|MINimum}
Change current setpoint Yes
Set Triggered Current
Setpoint
[[:]SOURce][<channel>]:CURRent[:LEVel]:TRIGgered[:AMP
Litude] {<current>|MAXimum|MINimum|DEFault}
Change triggered current setpoint Yes
Set (Immediate) Power
Setpoint
[[:]SOURce][<channel>]:POWer[:LEVel][:IMMediate][:AMP
Litude] {<power>|MAXimum|MINimum}
Change power setpoint Yes
Set Triggered Power
Setpoint
[[:]SOURce][<channel>]:POWer[:LEVel]:TRIGgered[:AMPLi
tude] {<power>|MAXimum|MINimum|DEFault}
Change triggered power setpoint Yes
Set (Immediate)
Voltage Setpoint
[[:]SOURce][<channel>]:VOLTage[:LEVel][:IMMediate][:A
MPLitude] {<voltage>|MAXimum|MINimum}
Change voltage setpoint Yes
Set Triggered Voltage
Setpoint
[[:]SOURce][<channel>]:VOLTage[:LEVel]:TRIGgered[:AMP
Litude] {<voltage>|MAXimum|MINimum|DEFault}
Change triggered votlage setpoint Yes
Set Voltage Slew Rate
Voltage
[[:]SOURce][<channel>]:VOLTage:SLEW:STEP{<slewrate-vo
ltage>|MAXimum|MINimum|DEFault}
Sets the voltage slew rate voltage change
for the programmed time interval
Yes
Set Voltage Slew Rate
Interval
[[:]SOURce][<channel>]:VOLTage:SLEW:INTerval{<slewrat
e-interval>|MAXimum|MINimum|DEFault}
Sets the voltage slew rate time interval for
the programmed voltage change
Yes
Set Over Current
Protection Level
[[:]SOURce][<channel>]:CURRent:PROTection[:OVER][:LEV
el] {<current>|MAXimum|MINimum}
Set the over current protection level Yes
Set Over Current
Protection
Shutdown State
[[:]SOURce][<channel>]:CURRent:PROTection[:OVER]:STAT
e <on-off-state>
Select over current protection to
shutdown(ON) or set alarm (OFF)
Yes
Query Over Current
Protection Tripped
[[:]SOURce][<channel>]:CURRent:PROTection[:OVER]:TRIP
ped?
Query if over current protection mechanism
has tripped
N/A
Set Under Current
Protection Level
[[:]SOURce][<channel>]:CURRent:PROTection:UNDer[:LEVe
l] {<current>|MAXimum|MINimum}
Set under current protection level Yes
Set Under Current
Protection
Shutdown State
[[:]SOURce][<channel>]:CURRent:PROTection:UNDer:STATe
<on-off-state>
Select under current protection to shutdown
(ON) or set alarm (OFF)
Yes
Query Under Current
Protection Tripped
[[:]SOURce][<channel>]:CURRent:PROTection:UNDer:TRIPp
ed?
Query if under current protection
mechanism has tripped
N/A
Set Over Power
Protection Level
[SOURce][<channel>]:POWer:PROTection[:OVER][:LEVel]
{<power>|MAXimum|MINimum}
Set the over power protection level Yes
Set Over Power
Protection
Shutdown State
[SOURce][<channel>]:POWer:PROTection[:OVER]:STATe
<on-off-state>
Select over power protection to shutdown
(ON) or set alarm (OFF)
Yes
Query Over Power
Protection Tripped
[[:]SOURce][<channel>]:POWer:PROTection[:OVER]:TRIPpe
d?
Query if over power protection mechanism
has tripped
N/A
Set Under Power
Protection Level
[[:]SOURce][<channel>]:POWer:PROTection:UNDer[:LEVel]
{<power>|MAXimum|MINimum}
Set under power protection level Yes
