Specifications and Characteristics
Mechanical Specification
244 Operating Manual for XDC Series Power Supply
Figure E.2 Power Supply Dimensions (12000 Watt unit)
10.37 in.
22.23 in.
19 in.
483 mm
263 mm
23.73 in.
603 mm
565 mm
