70 Operating Manual for XDC Series Power Supply
To set the Under-Power Protection:
Fold Protection options are:
• None: Fold protection disabled
• CC: Shutdown on entering CC mode
• CV: Shutdown on entering CV mode
• CP: Shutdown on entering CP mode
A programmable delay time causes the supply to wait before shutting down the
output.
Step # Do This You Will See
1 OVP SET 0V
2 Press repeatedly until the
desired setting appears.
UPP SET 0W
3 UPP SET 0W
4
Use both the Current and Voltage
knobs, or the numeric keypad, or the
arrow keys to enter a value (must be
between 0W and 103% of the unit’s
rated power).
UPP SET ####W
5 S/D if trip? N
6
Use the arrow keys to select Yes or
No. For this example, Yes is selected.
S/D if trip? Y
7 This setting is saved and the display
returns to its default operating mode.
PROT SET
ALARMS
PROT SET
ALARMS
ENTER
ENTER
ENTER
