6.1 Replacing Consumables 107
9. Replace the tray into the printer.
Replacing the Feed Roller in the Printer
1. Pull the tray out of the printer until it stops.
Hold the tray with both hands, lift the front
slightly, and remove it from the printer.
2. Remove any paper in the tray
3. Turn the feed roller until the roller hook can
be seen.
4. Pull the feed roller hook out of the notch on
the axle, and then slide the feed roller to the
left.
5. Repeat steps 3-4 and remove the other
feed roller from inside of the printer.
To Next Page
