General Procedures and Information
PHASER 3124 / PHASER 3125 09/06 6-17
• Rated Output Power
• Consumption Power
• Power cord length : 1830 ± 50mm
•Feature
Insulating resistance : 100 ohms or more (at DC 500V)
Insulating revisiting pressure : Must be no problem within 1 min. (at 1000Vac,10mA)
Leaking Current : under 3.5mA
Rising Time : within 2 Sec
Falling Time : over 20 ms
Surge : Ring Wave 6KV-500A (Normal, Common)
• Environment Condition
Operating temperature range : 0 ~ 40°C
Maintaining temperature range : -20 ~ 40°C
Preserving Humidity Condition : 10% ~ 90% RH
Operating atmospheric pressure range : 1atm
• EMI Requirement : CISPR ,FCC, CE, MIC,
• Safety Requirement : IEC950 UL1950, CSA950, C-UL,Semko, EK, CB, CCC(CCIB), GOST,
EPA, Power Save
Table 1: Rated Output Power
Items CH1 CH2 Remarks
Channel +5V +24.0V
Connector pin CON 3
5V PIN : 11, 12
GND PIN : 8, 9
CON 3
24V PIN : 2, 3, 4
GND PIN : 6, 7
Rated output +5V ± 5%
(4.75 ~ 5.25V)
+24V ± 5%
(20.4 ~ 27.6V)
Max. output cur-
rent
0.8A 2.5A
Peak loading
current
1.0A 2.7A 1ms
Ripple noise volt-
age
100mVp-p or less 500mVp-p or less
Maximum output 4W 60W
Peak output 5W 65W 1ms
No Items CH1 CH2 Remarks
1 Stand-by 1.0 A 0.4 A AVG : 55 Wh
2 Printing 1.0 A 2.5 A AVG : 350 Wh
3 Sleep-Mode 0.8 A 0.4 A AVG : 10 Wh
