Xerox Phaser 3124 Service Manual

Service Call Procedures
PHASER 3124 / PHASER 3125 09/06 1-3
SCP 1 Service Call Actions
Procedure
Throughout this manual, observe the following Warnings:
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
WARNING
Do not touch the fuser while it is hot.
WARNING
Take care during this procedure. Sharp edges may be present that can cause injury.
1. Take note of symptoms or error messages.
2. Ask the operator to describe or demonstrate the problem.
3. Make sure that:
• The power cord is connected to the wall outlet and to the machine.
• All cables are connected correctly.
4. If available, check the machine service log book for any previous actions that may be relevant
to the call.
5. Review any defective print or copy samples.
6. Perform ‘1 Initial Checks RAP’.

Xerox Phaser 3124 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	8 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	390 W
Power consumption (PowerSave)	6.5 W
Operating temperature (T-T)	10 - 32 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
