Xerox Phaser 3124 Service Manual

Status Indicator RAPs
2-14 09/06 PHASER 3124 / PHASER 3125
10 Paper Empty RAP
10A False indication error
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
The paper lamp on the operator panel is ON even when paper is loaded in the cassette.
10B No indication error
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
The paper lamp on the operator panel does not come ON when the paper cassette is empty.
Check and Cause Solution
1. The paper empty sensor actuator is dam-
aged or bent, PL 2.
1. Check and install a new paper empty sen-
sor actuator, PL 2 if necessary.
2. The main PBA, PL 1 may be defective. 2. Check and install a new main PBA, PL 1 if
necessary.
Check and Cause Solution
1. The paper sensor actuator is damaged or
bent, PL 2.
1. Check and install a new paper sensor actu-
ator, PL 2 if necessary.
2. The main PBA, PL 1 may be defective. 2. Check and install a new main PBA, PL 1 if
necessary.
