General Procedures and Information
PHASER 3124 / PHASER 3125 09/06 6-29
GP 6 Clearing Paper Jams
If a paper jam occurs, the Online/Error LED on the control panel turns red. Find and remove the
jammed paper.
In the Paper Exit Area
1. Open and close the front cover. The jammed paper is automatically ejected from the printer.
2. Gently pull the jammed paper out of the output tray, Figure 1.
Figure 1
If you do not see the jammed paper or if there is any resistance when you pull, stop pulling and
go to the next step.
3. Open the exit cover, PL 1 and fuser dummy, PL 3, Figure 2.
Figure 2
