Image Quality
PHASER 3124 / PHASER 3125 09/06 3-19
IQ 17 Uneven Vertical Lines
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
Printed vertical lines are not straight.
Check and Cause Solution
1.Check the LSU, PL 1. 1. Check and install new parts as necessary:
• LSU, PL 1
• Main PBA, PL 1
