General Procedures and Information
6-30 09/06 PHASER 3124 / PHASER 3125
4. Loosen the jammed paper if it is caught in the heat roller, PL 3. Gently pull the jammed paper
out, Figure 3.
CAUTION:
Do not touch the fuser while it is hot.
Figure 3
5. Close the fuser dummy, PL 3 and exit cover, PL 1. Printing automatically resumes.
In the standard tray
1. Remove the jammed paper by gently pulling it straight out. Make sure that all of the paper is
properly aligned in the standard tray, Figure 4.
Figure 4
