2.9 < System setup>
Ethernet
Speed
This item allows you to select the ethernet speed.
Clear
Setting
This item performs a simple reset and restores the
factory default settings for the network
configuration. This setting will only take effect after
you have reset the printer.
Network
Info.
This item prints a page showing the network
parameters you set.
802.1x
This item is for connecting with an authentication
server. If you need to connect this product to an
authentication server, set this item On, and select
one of the following authentication method. You can
select any method which the authentication server
supports among EAP-MD5, EAP-MSCHAPv2 and
PEAP.
Port 9100
This item lets you select whether or not you use port
9100.
• Off: You can disable the Port 9100 printing port.
• On: You can enable the Port 9100 printing port.
LPR
This item lets you select whether or not you use
LPR.
• Off: You can disable the LPR printing port.
• On: You can enable the LPR printing port.
IPP
This item lets you select whether or not you use the
IPP (Internet Printing Protocol) network connection.
• Off: You can disable the IPP.
• On: You can enable the IPP.
Item Explanation
Values: Auto, 10M Half, 10M Full, 100M Half,
100M Full
Values: Off, On
Values: Off, On
Values: Off, On
Values: Off, On
Printing a demo page
Print a demo page to make sure that the printer is operating correctly.
1 Press Menu and then OK when Information appears.
2 Press the Up/down arrow buttons until Demo Page appears and
press OK.
A demo page prints out.
Changing the display language
To change the language that is displayed on the control panel, follow
these steps:
1 Press Menu until System Setup appears on the bottom line of the
display and press OK.
2 Press OK when Language appears.
3 Press the Up/down arrow buttons to select the language you want
and press OK.
4 Press Start/Stop to return to Standby mode.
SLP
This item lets you select whether or not you use the
SLP (Service Location Protocol) network
connection.
• Off: You can disable the SLP.
• On: You can enable the SLP.
CentreWare
IS
This item lets you select whether or not you use the
embeded web server called CentreWare IS. If you
turn this item Off, you cannot connect to the
printer’s embeded web server.
Item Explanation
Values: Off, On
Values: Off, On

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
