Xerox Phaser 3600 User Manual

4.3 < Network setup (Phaser 3600/N, Phaser 3600/DN only)>
Setting Ethernet speed
You can select the communication speed for Ethernet connections.
1 Press Menu until Network appears on the bottom line of the
display and press OK.
2 Press the Up/down arrow buttons until Ethernet Speed appears
and press OK.
3 Press the Up/down arrow buttons until the speed you want
appears and press OK.
4 Press Start/Stop to return to Standby mode.
Restoring the network configuration
You can return the network configuration to its default settings.
1 Press Menu until Network appears on the bottom line of the
display and press OK.
2 Press the Up/down arrow buttons until Clear Setting appears and
press OK.
3 Press OK when Yes appears to restore the network configuration.
4 Power the printer off and back on.
Printing a network configuration page
The network configuration page shows how the network interface card
on your printer is configured.
1 Press Menu until Network appears on the bottom line of the
display and press OK.
2 Press the Up/down arrow buttons until Network Info. appears and
press OK.
3 Press OK when Yes appears.
The network configuration page prints out.
Configuring 802.1x
Your printer has 802.1x protocol on its network. 802.1x is a security
standard for port based network access control. It secures your network
against unauthorized access by requiring authentication before network
access and data transmission are allowed. There are 3 mutually
exclusive options for 802.1x authentication.
To use 802.1x, take the following steps:
1 Press Menu until Network appears on the bottom line of the
display and press OK.
2 Press the Up/down arrow buttons until 802.1x appears and press
OK.
3 Press the Up/down arrow buttons until On appears and press OK.
4 Press the Up/down arrow buttons until the desired authentication
method appears.
• EAP-MD5: EAP-MD5 (Extensible Authentication Protocol
Message Digest algorithm 5) is a message hashing scheme
between client and server to allow the transfer of user data in a
secure fashion.
• EAP-MSCHAPv2: EAP-MSCHAP (Extensible Authentication
Protocol Microsoft version of the Challenge-Handshake
Authentication Protocol). MSCHAP v2 is a one-way encrypted
password, mutual authentication process. MS-CHAPv2 uses
different hashing/encryption algorithms to encode the UserID and
passwords.
• PEAP: PEAP (Protected EAP).
5 Enter user name and passcode using Up/down arrow button.
6 Press OK to save the selection.
7 Press Start/Stop to return to Standby mode.
Configuring Port 9100
Your printer can use port 9100. To enable port 9100, take the following
steps:
1 Press Menu until Network appears on the bottom line of the
display and press OK.
2 Press the Up/down arrow buttons until Port 9100 appears and
press OK.
3 Press the Up/down arrow buttons until On appears and press OK.

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
