72 _Troubleshooting
2. Remove the jammed paper from the duplex unit.
If the paper does not come out with the duplex unit, remove the paper
from the bottom of the machine.
If you cannot find the jammed paper, or if there is any resistance
removing the paper, stop pulling and go to step 3.
3. Open the rear cover.
4. Pull the guide rear on each side down and remove the paper. Return the
guide rear to its original position.
5. Close the rear cover. Printing automatically resumes.
In the optional tray
If paper is jammed in the optional Tray, follow the next steps to release the
jammed paper.
1. Pull the optional tray open.
2. If you see the jammed paper, remove the paper from the machine by
gently pulling it straight out as shown below.
If you cannot find the jammed paper, or if there is any resistance
removing the paper, stop pulling and go to step 3.
3. Pull the tray half.
4. Remove the jammed paper by gently pulling the paper straight up and
out.
5. Insert the trays back into the machine. Printing automatically resumes.
1 Guide rear

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
