Page 7-14 Xerox WorkCentre 4118 System Administration Guide
Network Installation Using Internet Services
NOTE: Click the [Undo] button to cancel any changes made and return to the
previous values.
¾ You can Add or Edit a Trap Destination Address by making the following selections and
settings in the Trap Destination Addresses section of the frame:
Click the [Add] button or the [Edit] button to add a new address or amend an existing
address.
In the IP Address Destination section, enter or amend the IP Address and UDP Port
Number.
In the Traps section, enter the Trap Community Name and check the boxes corresponding
to the required Traps to be Received.
¾ Click the [Apply] button to implement any changes and return to the first screen.
NOTE: Click the [Undo] button to cancel any changes made and return to the
previous values.
¾ You can Delete a Trap Destination Address from the Trap Destination Addresses section
of the frame:
Highlight the required Address/Socket or Port and click the [Delete] button.
¾ Click the [Apply] button to implement any changes.
NOTE: Click the [Undo] button to cancel any changes made and return to the
previous values.
¾ Select the [Status] tab and then select [Reset Network Controller] to enable the selections
to take effect.
