Xerox WorkCentre 4118 System Administration Guide Page 7-7
Network Installation Using Internet Services
Ethernet
Use these instructions to set the rated speed for Ethernet using CentreWare Internet Services:
To complete the installation of the WorkCentre 4118, perform these steps:
¾ Enable CentreWare Internet Services (see “Enabling Internet Services” on page 7-5).
¾ At the CentreWare Internet Services Home Page for the WorkCentre 4118, select the
[Properties] tab.
¾ Select the plus symbol [+] to the left of the Connectivity folder in the Properties frame, and
then select the [+] symbol to the left of the Physical Connections folder.
¾ In the Properties frame, within the Physical Connections folder, select [Ethernet].
¾ Choose the appropriate [Rated Speed].
¾ Click the [Apply] button to implement any changes.
NOTE: Click the [Undo] button to cancel any changes made and return to the
previous values.
¾ Select the [Status] tab and then select [Reset Network Controller] to enable the selection
to take effect.
1
2
3
4
5
6
7
