Xilinx VC709 User Manual

36 www.xilinx.com VC709 Evaluation Board
UG887 (v1.0) February 4, 2013
Chapter 1: VC709 Evaluation Board Features
Table 1-11 lists the PCIe edge connector connections for Quad 115.
Table 1-12 lists the PCIe edge connector connections for Quad 114.
Table 1-11: GTH Quad 115 PCIe Edge Connector Connections
Quad 115 Pin Name
FPGA
(U1) Pin
Net Name
PCIe Edge Connector
(P1)
FFG1761 Placement
Pin Pin Name
MGTXTXP0_115_AE2 AE2 PCIE_TX3_P A29 PERp3 GTHE2_CHANNEL_X1Y20
MGTXTXN0_115_AE1 AE1 PCIE_TX3_N A30 PERn3 GTHE2_CHANNEL_X1Y20
MGTXRXP0_115_AC6 AC6 PCIE_RX3_P B27 PETp3 GTHE2_CHANNEL_X1Y20
MGTXRXN0_115_AC5 AC5 PCIE_RX3_N B28 PETn3 GTHE2_CHANNEL_X1Y20
MGTXTXP1_115_AC2 AC2 PCIE_TX2_P A25 PERp2 GTHE2_CHANNEL_X1Y21
MGTXTXN1_115_AC1 AC1 PCIE_TX2_N A26 PERn2 GTHE2_CHANNEL_X1Y21
MGTXRXP1_115_AB4 AB4 PCIE_RX2_P B23 PETp2 GTHE2_CHANNEL_X1Y21
MGTXRXN1_115_AB3 AB3 PCIE_RX2_N B24 PETn2 GTHE2_CHANNEL_X1Y21
MGTXTXP2_115_AA2 AA2 PCIE_TX1_P A21 PERp1 GTHE2_CHANNEL_X1Y22
MGTXTXN2_115_AA1 AA1 PCIE_TX1_N A22 PERn1 GTHE2_CHANNEL_X1Y22
MGTXRXP2_115_AA6 AA6 PCIE_RX1_P B19 PETp1 GTHE2_CHANNEL_X1Y22
MGTXRXN2_115_AA5 AA5 PCIE_RX1_N B20 PETn1 GTHE2_CHANNEL_X1Y22
MGTXTXP3_115_W2 W2 PCIE_TX0_P A16 PERp0 GTHE2_CHANNEL_X1Y23
MGTXTXN3_115_W1 W1 PCIE_TX0_N A17 PERn0 GTHE2_CHANNEL_X1Y23
MGTXRXP3_115_Y4 Y4 PCIE_RX0_P B14 PETp0 GTHE2_CHANNEL_X1Y23
MGTXRXN3_115_Y3 Y3 PCIE_RX0_N B15 PETn0 GTHE2_CHANNEL_X1Y23
MGTREFCLK0P_115_Y8 Y8 NC MGT_BANK_115
MGTREFCLK0N_115_Y7 Y7 NC MGT_BANK_115
MGTREFCLK1P_115_AB8 AB8 PCIE_CLK_Q0_N A13 REFCLK- MGT_BANK_115
MGTREFCLK1N_115_AB7 AB7 PCIE_CLK_Q0_P A14 REFCLK+ MGT_BANK_115
Table 1-12: GTH Quad 114 PCIe Edge Connector Connections
Quad 114 Pin Name
FPGA
(U1) Pin
Net Name
PCIe Edge Connector
(P1)
FFG1761 Placement
Pin Pin Name
MGTXTXP0_114_AK4 AK4 PCIE_TX7_P A47 PERp7 GTHE2_CHANNEL_X1Y16
MGTXTXN0_114_AK3 AK3 PCIE_TX7_N A48 PERn7 GTHE2_CHANNEL_X1Y16
MGTXRXP0_114_AG6 AG6 PCIE_RX7_P B45 PETp7 GTHE2_CHANNEL_X1Y16
MGTXRXN0_114_AG5 AG5 PCIE_RX7_N B46 PETn7 GTHE2_CHANNEL_X1Y16
MGTXTXP1_114_AJ2 AJ2 PCIE_TX6_P A43 PERp6 GTHE2_CHANNEL_X1Y17
