Xilinx VC709 User Manual

VC709 Evaluation Board www.xilinx.com 35
UG887 (v1.0) February 4, 2013
Feature Descriptions
PCIE_TX3_P AE2 A29 PERp3
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y20
PCIE_TX3_N AE1 A30 PERn3
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y20
PCIE_TX4_P AG2 A35 PERp4
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y19
PCIE_TX4_N AG1 A36 PERn4
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y19
PCIE_TX5_P AH4 A39 PERp5
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y18
PCIE_TX5_N AH3 A40 PERn5
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y18
PCIE_TX6_P AJ2 A43 PERp6
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y17
PCIE_TX6_N AJ1 A44 PERn6
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y17
PCIE_TX7_P AK4 A47 PERp7
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y16
PCIE_TX7_N AK3 A48 PERn7
Integrated Endpoint block
transmit pair
GTHE2_CHANNEL_X1Y16
PCIE_CLK_Q0_P AB8 A13 REFCLK+
Integrated Endpoint block
differential clock pair
from PCIe
MGT_BANK_115
PCIE_CLK_Q0_N AB7 A14 REFCLK-
Integrated Endpoint block
differential clock pair
from PCIe
MGT_BANK_115
PCIE_PRSNT_B J49 2, 4, 6 A1 PRSNT#1
J49 Lane Size Select
jumper
NA
PCIE_WAKE_B AV33 B11 WAKE#
Integrated Endpoint block
wake signal
U1 FPGA Bank13 Pin AV33
PCIE_PERST_B AV35 A11 PERST
Integrated Endpoint block
reset signal
U1 FPGA Bank13 Pin AV35
Table 1-10: PCIe Edge Connector Connections (Cont’d)
Net Name FPGA (U1) Pin
PCIe Edge
Connector (P1)
Function FFG1761 Placement
Pin Name
