EV System Layout
Motor Controller
AC charging Refer to page 15
Charger/DC converter
Power battery Refer to page 12
DC charging port Refer to page 17
Air-conditioning compressor
Drive motor
Warning
●
The orange wiring harness on
the whole vehicle are high-
voltage. It is forbidden to
touch the high-voltage wiring
harness or high-voltage
parts connected high-voltage
wiring harness, Be aware of
electric shock!
