Xtrails ADPRO PRO-18 - Surface or Volumetric Detector

14 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
 PRO-85 *)
 PRO-85H *)
 PRO-85H-IP65 *)
 PRO-100
 PRO-100I
 PRO-100H
 PRO-100HI
 PRO-100HIS
 PRO-100H-IP65
 PRO-100IS-IP65
 PRO-250H
*)
These ADPRO PIR detectors have volumetric properties and a narrow angle of aperture.
5.3.6 Surface or Volumetric Detector
Planning Notes
The key point in monitoring land surfaces rests on the specific nature of the objects;
depending on that, planning should be for a so-called surface detector or a volumetric
detector.
The following, from the extensive range of ADPRO PRO PIR detectors, correspond in terms
of nominal range, number of zones (‘finger’) and monitoring angle of aperture:
 PRO-18
 PRO-18H
 PRO-18H-IP65
 PRO-18W
 PRO-18WI
 PRO-18WIS
 PRO-18WH
 PRO-18WHI
 PRO-18WH-IP65
 PRO-30
 PRO-40
 PRO-51 *)
 PRO-85 *)
 PRO-85H *)
 PRO-85H-IP65
*)
*)
These ADPRO PIR volumetric detectors have curtain-like properties and a narrow angle of
aperture.
