Page #36 background imageLoading...
Page #36 background image
28 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
7 Operating Modes
7.1 Selectable Operating Modes
The detector can work in two operating modes:
Hardware mode
Software mode
The devices of all models are provided with the following features.
7.1.1 Modes
7.1.1.1 Hardware Mode
In hardware mode the detector can be configured and operated by means of DIP switches
located on the connector board of the detector.
By default, the detector operates in hardware mode and the DIP switches are pre-set as
follows:
Default Settings of
DIP Switches
DIP Switch Status Function
1 ON Sensitivity adjustment
2 OFF
3 ON ATD
(Volumetric Models
only)
4 ON Pulse count
(PRO-45D(H) only) 4 OFF Directional detection
5 OFF Test
6 ON Anti-tamper
(PRO-51, PRO-85(H),
PRO-100(H), PRO-
250H only)
7 ON Mounting height
8 OFF No function
NOTE!
More setting options are available in software mode.
7.1.1.2 Software Mode
In software mode, the detector can be configured and operated using the ADPRO®
Windows® PRO software.
Adjustable Functions only in Software Mode
The following adjustments are only available in software mode:
The following adjustments are only available in software mode:
Individual sensitivity adjustment (20% - 140% or 50%-150%, see individual detector
specification)
Individual pulse count for volume models (0-10 pulses)
Bi-directional detection for the PRO-45D(H) models
Individual anti-tamper alarm output (transistor and/or relay)
Activation/deactivation of left/ right channels for PRO-45D(H) models
