Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
Because of these circumstances a curtain detector should be used; depending on the size of
the area the following detectors might be considered.
For monitoring the sides:
 PRO-40
 PRO-45, PRO-45H, PRO-45D, PRO-45DH
 PRO-51
 PRO-85, PRO-85H
 PRO-100, PRO-100H
 PRO-250H
In this case a very narrow PRO-45 was chosen.
For extra coverage in the sides, the following detectors are offered:
 PRO-18W, PRO-18WH
In this case a wide-angle PRO-18WH was chosen.
NOTE!
Creep zones are better monitored by the volumetric detectors in the
corners.
Over-length is avoided by using additional fixed IR-blocking foils.
These have to be maintained regularly so that loose swinging is not
possible.
5.4.3 Continuous Monitoring of an Area
5.4.3.1 Requirements
