38 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
3 OFF ATD
9.3 Vandalism Protection
The vandalism protection function offers increased protection against vandalism. As soon as
the previously stored alignment of the detector is changed a continuous alarm is triggered.
By default, the vandalism protection function is activated on the transistor output (open
collector).
Standard DIP Switch
Setting
DIP-Switch Status Function
6 ON Vandalism Protection
Deactivation
To deactivate the vandalism protection function, carry out the following step:
Turn DIP switch 6 to “OFF”.
DIP DIP-Switch Status Function
6 OFF Vandalism Protection
Software Operation
To activate the vandalism protection funcion in software operation, carry out the following
steps:
1. Open the ‘Setting’ dialogue of the PRO software,
2. Set the option for vandalism protection to “ON”.
There are more options in chapter 10 (Software Installation).
Resetting the position after an unauthorised intrusion
These are the ways to stop the alarm:
1. Remount the detector in its original position.
2. Reset the position of the detector.
Resetting the Position – Hardware Operation
To reset the position of the detector within c. 60 seconds -the vandalism protection sensor
remains active, follow these steps:
1. Leave the housing of the detector closed,
2. Disconnect the detector from the power supply,
3. Connect the detector to the power supply,
4. Align the detector again.
The new position of the detector will be automatically saved after c. 60 seconds.
To reset the position of the detector within c. 5 minutes, follow these steps:
1. Leave the detector connected to the power supply,
2. Open the detector housing to deactivate the vandalism protection sensor,
3. Close the detector housing to activate the vandalism protection sensor,
4. Align the detector again.
