DPRO Passive-Infrared (PIR) PRO Series by Xtralis Planning and Commissioning Manual
16.1.3 ADPRO Passive-IR-Detector (PIR) PRO-30
Specifications ADPRO PRO-30
Model Item code PRO-30: 202383
Max. Nominal Length 30 m
Nominal Width 20 m
Nominal Aperture angle (AA) 50°
Sensitivity adjustment
(% of default adjustment)
DIP-Switch: 40%, 75% 100%
PRO Software: 20 - 140%
Internal Switches
 Sensitivity
 ATD
 Pulse Counter
 Test
 Vandalism Detection
 Nominal mounting height
Nominal detection ranges
16.1.4 ADPRO Passive-IR-Detector (PIR) PRO-40
Specifications ADPRO PRO-40
Model Item code PRO-40: 202384
Max. Nominale Length 40 m
Nominal Width 10 m
