84 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
16.1.2 ADPRO Passive-IR-Detector (PIR) PRO-18W and PRO-18WH
Specifications ADPRO PRO-18W/ PRO-18WH
Model Item code
PRO-18W: 201313
PRO-18WH: 201727
PRO-18WH/IP65 202489
Max. nominal Length
PRO-18W: 21 m
PRO-18WH: 27 m
Nominal Width PRO-18W: 24 m
PRO-18WH: 30 m
Nominal Aperture angle (AA) 90°
Sensitivity adjustment
(% of default adjustment)
DIP-Switch: 40%, 75% 100%
PRO-Software: 20 - 140%
Internal Switches
Sensitivity
ATD
Pulse Counter
Test
Vandalism Detection
Nominal mounting height
Nominal detection ranges
