86 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
Specifications ADPRO PRO-40
Nominal Aperture angle (AA) 15°
Sensitivity adjustment
(% of default adjustment)
DIP-Switch: 40%, 75% 100%
PRO Software: 20 - 140%
Internal Switches
Sensitivity
ATD
Pulse Counter
Test
Vandalism Detection
Nominal mounting height
Nominal detection ranges
16.1.5 ADPRO Passive-IR-Detector (PIR) PRO-51
Specifications ADPRO PRO-51
Model Item code PRO-51: 202385
Max. Nominal Length 50 m
Nominal Width 23 m
Nominaler Aperture angle (AA) 26°
Sensitivity and range adjustment DIP-Switch: Length: 30, 40, 50 m
PRO Software: Length: 30, 40, 50 m
Sensitivity: 50 – 150%
Internal Switches
Range (length)
ATD
Pulse Counter
Test
Vandalism Detection
Nominal mounting height
Nominal detection ranges
