Doc. 20780_03 87
A
DPRO Passive-Infrared (PIR) PRO Series by Xtralis Planning and Commissioning Manual
16.1.6 ADPRO Passive-IR-Detector (PIR) PRO-85 and PRO-85H
Specifications ADPRO PRO- 85/PRO-85H
Model Item code
PRO-85: 201779
PRO-85H: 201780
PRO-85H/ IP65 202494
Max. Nominal Length
PRO-85: 60 m
PRO-85H: 75 m
Nominal Width PRO-85: 18 m
PRO-85H: 23 m
Nominaler Aperture angle (AA) 17°
Sensitivity and range adjustment PRO-85: DIP-Switch: Length: 30, 45, 60 m
PRO Software: Length: 30, 45, 60 m
PRO Software: Sensitivity: 50- 150%
PRO-85H: DIP-Switch: Length: 40, 60, 75 m
PRO Software: Length: 40, 60, 75 m
PRO Software: Sensitivity: 50- 150%
Internal Switches
Range (length)
ATD
Pulse Counter
Test
Vandalism Detection
Nominal mounting height
Nominal detection ranges
