48 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
9. Click (Finish).
The ADPRO PRO Windows® Software is now installed in your computer in the specified
directory and the following structure is created:
Each sub-folder is responsible for a specification action as follows:
: Contains all images taken using the Software.
: Contains all detector configuration files.
: Contains all statistics and debugger files.
: Contains all detectors definition files. Each detector model
requires its specific INI file.
: Contains specific data relevant to the display structure such as
logo on images, etc. This file must not be deleted.
: Installation program for setup and signal display.
10.2.3 Configure Communication Port
It is important to configure the communication port that will be dedicated to the Software
before you start using it.
