Doc. 20780_03 35
DPRO Passive-Infrared (PIR) PRO Series by Xtralis Planning and Commissioning Manual
DIP Switch Settings
for Software Mode
DIP-Switch Status Function
1 ON Software mode
2 ON
Display the Signal Strength
5. With the PRO software (see chapter 10), you can change the settings (instead of
using DIP switches) and check the detector’s signal and alarm performance by doing
a walk test (instead using of the CT PRO).
