Page #90 background image
82 Doc. 20780_03
Planning and Commissioning Manual ADPRO Passive-Infrared (PIR) PRO Series by Xtralis
SPECIFICATIONS All ADPRO PRO-PIR Detectors
High-Performance H-versions : -40° up to +60°C
Cable connection
(removable screw terminals)
PRO-xxx 2 x 4-7 mm (0.16” - 0.27”)
PRO-250H 2 x 6 – 9 mm (P11, 0,24” - 0,35”)
Cable glands PRO-xx Outside cable diameter: Ø 9 – 14 mm (M16)
IEC 60423:2007(DIN EN 60423) – cable glands
PRO-250H Outside cable diameter: Ø 4 – 10 mm (PG11)
Weight All PRO-xxx
(except PRO-250H)
: approx. 900 g,
w/ metal bracket
PRO-250H : approx. 1,5 kg, w/o bracket
Dimensions (L x B x H) in mm All PRO-xxx
(except PRO-250H)
: 247 x 100 x 104
PRO-250H : 272 x 100 x 104
Mounting All PRO-xxx (except PRO-250H):
Metal bracket (included in delivery)
Pole mount ZA P-L1 (optional)
Cable managed bracket PRO-CMB-W (optional)
PRO-250H:
Metal-Pole-/Wall-Mount AD 653 (optional)
IP rating PRO-xxx: IP54
The following models have been tested by TEA AG,
Schweizerischer Prüfstellendienst (Akkreditierungs-Nr. STS
506) to be compliant with the protection rating IP65:
PRO-18H-IP65
PRO-18WH-IP65
PRO-45H-IP65
PRO-45DH-IP65
PRO-85H-IP65
PRO-100H-IP65
The following models are compliant to IP66 rating:
PRO-85H-IP66
PRO-100H-IP66
Compliance All ADPRO PRO-PIR detctors are designed to fulfill the
following guidelines:
UK: BS8418_Form 172 Basic Guide for Installers (CCTV with
PIR trigger)
(provided that all detectors are RS-485 cabled and in a permanent
online operation mode monitored by an alarm receiving, which
requires an interconnection to an intrusion, access control or CCTV
security system or an alarm management station)
All ADPRO PRO-PIR detectors have been tested and are
certified by the accredited test house HTZ in Zürich (notified
body number D.E.07.36/37_2), Switzerland and comply fully
to the following standards:
2004/108/EG
Directive of the European
Parliament relating to
electromagnetic compatibility
EN 61000–6–3:2007
Electromagn. Compat. – EMC
EN 50130–4
+A1+A2:2003 –
Electromagn. Compat. – Immunity
