VESDA-EîVEP-A10-P Product Guide
www.xtralis.com 11
2.7 Specifications
Specification Value
Supply Voltage 18 to 30 VDC (24 VDC Nominal)
Power Consumption @24 VDC
Dimensions (WHD) 350 mm x 225 mm x 135 mm
(13.8 in x 8.9 in x 5.3 in)
Weight 4.1 kg (9.1 lb)
Operating Conditions
Please consult your Xtralis representative for
information on operation outside these parameters
or where sampled air is continually above 0.05%
obs/m (0.015% obs/ft) under normal operating
conditions.
Temperature:
l Ambient: 0°C to 39°C (32°F to 102°F)
l Sampled Air: -20°C to 60°C (-4°F to 140°F)
l Tested to: -20°C to 55°C (-4°F to 131°F)*
* UL:-20°C to 50°C (-4°F to 122°F)
Humidity:
l 10-95% RH, non-condensing
Storage Conditions
(Non-operational)
l Humidity: Dry (<95%)
l Temperature: 0° to 85°C
l Must not be exposed to sunlight or other radiation sources
Sampling Pipe Network l Maximum length per pipe when using four straight
pipes:
l Four pipe VEP-A10-P:î70 m (230 ft)
l Maximum total pipe length (with branches):
l Four pipe VEP-A10-P:î560 m (1,837 ft)
l Pipe Modeling Design Tool:îASPIRE
l Minimum airflow per pipe: 15 l/m
Note: Standards compliance of a particular pipe network
must be determined using ASPIRE.
Inlet Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS)
Exhaust Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS) via
adaptor
Relays l 7 programmable relays
l Contacts rated 2A @ 30 VDC (Resistive)
l Programmable to latch or not latch alarm or fault states
IP Rating IP 40
(not UL tested)
Mounting Upright or inverted
Cable Access 4 x 26 mm (1 in) ports
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 24-14 AWG)
Interfaces l USB (Type 2)
l Ethernet (RJ45)
l WiFi, 802.11 b/g/n
Dynamic Range 0.0002%/m (0.00006%/ft) to 32%/m (10%/ft)
Sensitivity Range 0.005 to 20% obs/m (0.0016 to 6.25% obs/ft.)
Tableî2-2: VEP-A10-P Detector Specifications
