3500 Series Flat Panel Industrial PC
74
Startup
Type kputil to run the full keypad utility.
Utility Batch Mode
You can also use a batch file to reprogram keypads. This feature is useful if you wish
to reprogram many units with customized keypad macros without having to enter the
full keypad utility for each unit. Once the full utility has been used to create and save
keypad macros, the files containing these macros can be included on a disk with the
keypad utility and then used to reprogram other units from a batch file.
The command keypad filename runs the keypad utility batch mode.
“Filename” is the file containing the new keypad macros. The filename extension
must be included.
Main Menu
Figure 4-1 illustrates the Main Menu.
Exit Files Macros Upload Download Utilities
Xycom Automation KP Utility: MAIN L-Arrow, R-Arrow, Enter
Figure 4-1. Main Menu
Exit
Exit closes open files and exits the utility. ESC can also be used for this purpose and
for exiting the other menus.
