Yamaha F25A - Flywheel Magneto Removal; Service Points; Starter Hub Removal

5-5
POWR
E
FLYWHEEL MAGNETO
SERVICE POINTS
Starter hub removal
1. Remove:
●
Starter hub
Universal clutch holder:
YM-91042/90890-04086
Flywheel magneto removal
1. Remove:
●
Flywheel magneto nut
Å For USA and CANADA
ı Except for USA and CANADA
CAUTION:
The major load should be applied in the
direction of the arrows. If the load is not
applied as shown, the flywheel holder may
easily slip off.
Flywheel holder:
YB-06139/90890-06522
Å
ı
2. Remove:
●
Flywheel magneto
Å For USA and CANADA
ı Except for USA and CANADA
CAUTION:
●
Keep the nut side flush with the crank-
shaft end until the flywheel magneto
comes off the tapered portion of the
crankshaft.
●
To prevent damage to the engine or
tools, screw in the universal-puller set
bolts evenly and completely so that the
universal puller plate is parallel to the fly-
wheel magneto.
Universal puller:
YB-06117/90890-06521
Å
ı
