Yamaha F25A - Propeller Shaft Assy. Removal; Oil Seal Housing Assembly

6-7
E
LOWR
PROPELLER SHAFT ASSY.
SERVICE POINTS
Propeller shaft assy. removal
(along with the propeller shaft housing
assy.)
1. Remove:
●
Propeller shaft assy.
(along with the propeller shaft housing
assy.)
Å For USA and CANADA
ı Except for USA and CANADA
Bearing housing puller:
YB-06234 1 /90890-06503 3
Universal puller 2 :
YB-06117
Stopper guide plate 4 :
90890-06501
Center bolt 5 :
90890-06504
Å
ı
Oil seal housing assembly
1. Install:
●
Oil seals
Oil seal position:
a : 12.5 ~ 13.0 mm
(0.49 ~ 0.51 in)
b : 5.5 ~ 6.0 mm (0.22 ~ 0.24 in)
Driver rod 1 :
YB-06229/90890-06606
Ball bearing attachment
(oil seal installer) 2 :
YB-06022/90890-06635
