Yamaha F25A - Page 308

7-12
E
BRKT
POWER TRIM AND TILT (PTT) UNIT
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
5 Anode 1
6 Bolt 2
7 Bushing 1
8 Bushing 2
9 Shaft 1
10 Circlip 1
11 Shaft pin 1
12 Bushing 2
13 Bushing 1
14 PTT unit 1
Reverse the removal steps for installation.
