6 - 1
–+
ELEC
ELECTRICAL COMPONENTS AND WIRING DIAGRAM
EC600000
ELECTRICAL
EC610000
ELECTRICAL COMPONENTS AND WIRING DIAGRAM
TT-R90
EC611000
ELECTRICAL COMPONENTS
1 CDI magneto
2 CDI unit
3 Ignition coil
4 Spark plug
5 ENGINE STOP switch
6 Thermo switch
7 Carburetor heater
8 Rectifier/regulator
COLOR CODE
B...................... Black
Br .................... Brown
G ..................... Green
O ..................... Orange
R ..................... Red
W..................... White
EC612000
WIRING DIAGRAM
G/W
B/R
W/LW/R
Br G
RW
WB
Y/R
O
B
O
B
B
B
Y/R
Y
W
Y/R
B
W
Y
B
G G/W
B/W
B/W
Br B/R
W
WW
Y
O O
B
BW/LY/R
R
W
B
B
B
W/R
Y/R
OFF
RUN
B
Y/R
B
B
Y
Y
1
2
3
4
5
6
7
8
B/R...................Black/Red
B/W..................Black/White
G/W..................Green/White
W/L ..................White/Blue
W/R..................White/Red
