ELEC
6 - 3
IGNITION SYSTEM
EC620000
IGNITION SYSTEM
INSPECTION STEPS
Use the following steps for checking the possibility of the malfunctioning engine being attributable to
ignition system failure and for checking the spark plug which will not spark.
N
OTE:
● Remove the following parts before inspection.
1) Seat
2) Fuel tank
● Use the following special tools in this inspection.
Spark gap test
Clean or replace
spark plug.
Check entire ignition
system for connection.
Repair or replace.
Check main switch.
(TT-R90E only)
Replace.
Check “ENGINE STOP”
switch.
Replace.
Check ignition coil. Primary coil Replace.
Secondary coil Replace.
Check CDI magneto. Pickup coil Replace.
Source coil Replace.
Replace CDI unit.
Dynamic spark tester:
YM-34487
Ignition checker:
90890-06754
Pocket tester:
YU-3112-C/90890-03112
No Spark
OK
OK
OK
OK
Spark
No good
No good
No good
No good
No good
No good
OK
No good
