GEN
INFO
SPEZIALWERKZEUGE
YU-33270-B, 90890-01362
Polrad-Abzieher
Zum Demontieren des Rotors
YU-33270-B
90890-01362
ACC-QUICK-GS-KT
90890-85505
Quick gasket
®
YAMAHA-Dichtmasse Nr. 1215
Zum Abdichten der Kurbelgeh
ä
use-Pa
ß
fl
ä
chen
ACC-QUICK-GS-KT
90890-85505
Teilenummer
Werkzeug/Anwendung
Abbildung
1 - 8
43
45
