Yamaha YZ250F(E) - Installing the Kickstarter Lever

CLUTCH
5-43
EAS1SM1247
INSTALLING THE KICKSTARTER LEVER
1. Install:
• Kickstarter lever “1”
• Washers
• Bolt (kickstarter lever)
TIP
Install so that there is a clearance “a” of 5 mm
(0.2 in) or more between the kickstarter lever
and the frame and that the kickstarter lever
does not contact the right crankcase cover
when it is pulled.
Bolt (kickstarter lever)
33 Nm (3.3 m·kgf, 24 ft·lbf)
T
R
.
.
1
a
