CRANKSHAFT ASSEMBLY AND BALANCER SHAFT
5-66
EAS1SM1284
CRANKSHAFT ASSEMBLY AND BALANCER SHAFT
Removing the crankshaft assembly and balancer shaft
Order Part name Q’ty Remarks
Crankcase
Separate.
Refer to “CRANKCASE” on page 5-61.
Transmission Refer to “TRANSMISSION” on page 5-69.
1 Balancer shaft 1
2 Crankshaft assembly 1
For installation, reverse the removal proce-
dure.
M
M
1
2
