CRANKCASE
5-63
Removing the bearing and oil seal
Order Part name Q’ty Remarks
Transmission Refer to “TRANSMISSION” on page 5-69.
Shift cam and shift fork Refer to “TRANSMISSION” on page 5-69.
1 Circlip 2
2Oil seals 3
3 Bearing 11
For installation, reverse the removal proce-
dure.
LT
LT
LT
2
3
3
3
3
3
3
3
3
3
New
1
1
2
3
New
New
LT
22 Nm (2.2 m
•
kgf, 16 ft
•
Ibf)
T
.R.
