Yamaha YZ250F(E) - Page 304

FUEL INJECTION SYSTEM
8-18
3 Connection of sub wire har-
ness coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected 
Connect the coupler secure-
ly, or repair/replace the sub-
wire harness.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
4 Wire harness continuity. Open or short circuit  Re-
place the wire harness.
Between throttle position
sensor coupler and ECU cou-
pler.
yellow–yellow
blue–blue
black/blue–black/blue
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
5 Mounted condition of throttle
position sensor.
Check for looseness or
pinching.
Check the mounted condition
for correctness.
Improperly mounted sensor
 Remount or replace the
sensor.
Refer to “ADJUSTING THE
THROTTLE POSITION SEN-
SOR” on page 7-9.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
6 Applied voltage of throttle po-
sition sensor lead.
Check the applied voltage.
(black/blue–blue)
Refer to “CHECKING THE
THROTTLE POSITION SEN-
SOR” on page 8-44.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
Location of discon-
nected lead
Output
voltage
Disconnected
ground lead
5 V
Disconnected out-
put lead
0 V
Disconnected
power supply lead
0 V
7 Defective throttle position
sensor.
Execute the diagnostic mode.
(Code No. 1)
When the throttle is fully
closed, 11–14 displays.
When the throttle is fully
opened, 109–116 displays.
Incorrect display range 
Replace the throttle position
sensor.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
8 Faulty ECU Replace the ECU.
Fault code 15
Symptom Throttle position sensor: open or short circuit detected.
